Haws

Manufacturer: Haws, Manufacturer Part Number: 1212SFVModel 1212SFV vandal resistant, filtered, wall-mounted chilled indoor wall-mount indoor unit with dual fountain design in 304 satin-finish stainless steel. Features include vandal-resistant stainless steel anti-rotational bubbler heads, model 5874 solid bar stock steel push button, and scratch resistant LED-illuminated bottle filler. The 3000-gallon (11,356 L) filter with Electronic Lifecycle Control turns filter indicator light off when capacity is reached. Energy-saving mode powers down unit and lights after 2 hours of inactivity; programmable for specific days of the week. Digital LED interface displays status and error codes. Bottle filler drains to waste and auto-purges after 24 hours of non use. CSA certified to comply with NSF/ANSI/CAN 61: Q ≤ 1, NSF/ANSI/CAN 372, ASME A112.18.1/CSA B125.1, UL 399 and CSA C22.2 No. 120. ADA compliant to ICC A117.1, CSA B651, DOJ’s 2010 ADA Standards for Accessible Design when properly installed. ASHRAE 18 compliant chilling capacity of 8.0 gallon per hour of 50 degree drinking water, based on 80 degree inlet water and 90 degree ambient temperature. FCC and CAN ICES - 3(A)/NMB-3(A). Electric water coolers are not recommended or designed for outdoor applications or enclosed pool areas (chlorine), and failure to heed these conditions may void warranty.Spec Sheet INSTALL DRAWING Parts Break Down O&M MANUAL WARRANTY

Manufacturer: Haws, Manufacturer Part Number: 1212SFVNModel 1212SFVN vandal resistant, filtered, wall-mounted non-chilled indoor wall-mount indoor unit with dual fountain design in 304 satin-finish stainless steel. Features include vandal-resistant stainless steel anti-rotational bubbler heads, model 5874 solid bar stock steel push button, and scratch resistant LED-illuminated bottle filler. Energy-saving mode powers down unit and lights after 2 hours of inactivity; programmable for specific days of the week. Digital LED interface displays status and error codes. Bottle filler drains to waste and auto-purges after 24 hours of non use. CSA certified to comply with NSF/ANSI/CAN 61: Q ≤ 1, NSF/ANSI/CAN 372, ASME A112.18.1/CSA B125.1, UL 399 and CSA C22.2 No. 120. ADA compliant to ICC A117.1, CSA B651, DOJ’s 2010 ADA Standards for Accessible Design when properly installed. FCC and CAN ICES - 3(A)/NMB-3(A). Electric water coolers are not recommended or designed for outdoor applications or enclosed pool areas (chlorine), and failure to heed these conditions may void warranty.Spec Sheet INSTALL DRAWING Parts Break Down O&M MANUAL WARRANTY

Manufacturer: Haws, Manufacturer Part Number: 1211SFVModel 1211SFV vandal resistant, filtered, wall-mounted chilled indoor wall-mount indoor unit with single ADA fountain design in 304 satin-finish stainless steel. Features include vandal-resistant stainless steel anti-rotational bubbler head, model 5874 solid bar stock steel push button, and scratch resistant LED-illuminated bottle filler. Energy-saving mode powers down unit and lights after 2 hours of inactivity; programmable for specific days of the week. Digital LED interface displays status and error codes. Bottle filler drains to waste and auto-purges after 24 hours of non-use. CSA certified to comply with NSF/ANSI/CAN 61: Q ≤ 1, NSF/ANSI/CAN 372, ASME A112.18.1/CSA B125.1, UL 399 and CSA C22.2 No. 120. ADA compliant to ICC A117.1, CSA B651, DOJ’s 2010 ADA Standards for Accessible Design when properly installed. ASHRAE 18 compliant chilling capacity of 8.0 gallon per hour of 50 degree drinking water, based on 80 degree inlet water and 90 degree ambient temperature. FCC and CAN ICES - 3(A)/NMB-3(A). Electric water coolers are not recommended or designed for outdoor applications or enclosed pool areas (chlorine), and failure to heed these conditions may void warranty. Spec Sheet INSTALL DRAWING Parts Break Down O&M MANUAL WARRANTY

Manufacturer: Haws, Manufacturer Part Number: 1211SFVNModel 1211SFVN vandal resistant, filtered, wall-mounted non-chilled indoor wall-mount indoor unit with single ADA fountain design in 304 satin-finish stainless steel. Features include vandal-resistant stainless steel anti-rotational bubbler head, model 5874 solid bar stock steel push button, and scratch resistant LED-illuminated bottle filler. Energy-saving mode powers down unit and lights after 2 hours of inactivity; programmable for specific days of the week. Digital LED interface displays status and error codes. Bottle filler drains to waste and auto-purges after 24 hours of non-use. CSA certified to comply with NSF/ANSI/CAN 61: Q ≤ 1, NSF/ANSI/CAN 372, ASME A112.18.1/CSA B125.1, UL 399 and CSA C22.2 No. 120. ADA compliant to ICC A117.1, CSA B651, DOJ’s 2010 ADA Standards for Accessible Design when properly installed. FCC and CAN ICES - 3(A)/NMB-3(A). Electric water coolers are not recommended or designed for outdoor applications or enclosed pool areas (chlorine), and failure to heed these conditions may void warranty.Spec Sheet INSTALL DRAWING Parts Break Down O&M MANUAL WARRANTY

Manufacturer: Haws, Manufacturer Part Number: 9009Model 9009 waste water container adapts to model 9008 to be used with models 7500 or 9010. Twenty gallon (75.7 L) yellow container constructed of tough polymer resin.

Manufacturer: Haws, Manufacturer Part Number: 83008309LFAHaws® Axion® MSR Emergency Shower & Eye/Face Wash - Model Number: 83008309|UOM: EA - First Aid and Emergency Products - Emergency Eyewash Equipment

Manufacturer: Haws, Manufacturer Part Number: 7260B7270BLFAHaws® Axion® MSR Wall-Mounted Eye/Face Wash - Model Number: 7260B7270B|UOM: EA - First Aid and Emergency Products - Emergency Eyewash Equipment

Manufacturer: Haws, Manufacturer Part Number: 7501LFAHaws® Portable Eyewash Station - Model Number: 7501|UOM: EA - First Aid and Emergency Products - Emergency Eyewash Equipment

Manufacturer: Haws, Manufacturer Part Number : RK5715Model RK5715 repair kit includes the flow control for the Haws model 5715 bubbler head on the Haws 1200 series water coolers.

Manufacturer: Haws, Manufacturer Part Number : RK5716Model RK5716 repair kit includes the flow control for the Haws model 5716 stainless steel bubbler head on the Haws 1200 series water coolers.

Manufacturer: Haws, Manufacturer Part Number : 5715The Haws 5715 replacement anti-rotational bubbler head is designed with a shielded fountain spout incorporating an anti-squirt angled drinking stream. A pressure compensating flow control supplies a laminar flow nozzle. Made with a plastic main body and a antimicrobial rubber mouth guard.

Manufacturer: Haws, Manufacturer Part Number : 1920HPSModel 1920HPS wall mounted high-polished stainless steel bottle filler shall include 100% lead-free waterways, 1 gpm (3.78 L) laminar flow, push-button operated stainless steel valve with front-accessible cartridge and flow adjustment, and polished stainless steel construction. It can be used as a stand-alone station, or mounted above the Haws‚® 1001HPS and 1011HPS series drinking fountains.Note***** This item requires a mounting plate for installation. Please purchase mounting plate SKU# 6700 or SKU# 6700R .*****

Manufacturer: Haws, Manufacturer Part Number : 6472Model 6472, Surface Mount replacement drain pan assembly for Haws models 2000SMS and 2000SMSN, which includes the grate, basin and gasket.

Manufacturer: Haws, Manufacturer Part Number : 6423Model 6423 replacement filter is used on the Hydration By Haws models (2000S, 2000SN, 2000SMS and 2000SMSN) and is tested and certified by CSA against NSF/ANSI Standard 42 for the reduction of chlorine (taste and odor) and against NSF/ANSI Standard 53 for the reduction of lead and 99.99% of cysts. It is a carbon block filter cartridge with a service life of 1 year/2,500 gallons (9463 L). Filter contains an onboard chip to store total gallon usage; this chip interfaces with an Electronic Lifecycle Control system to allow water flow only until the filter reaches its total gallon capacity.

Manufacturer: Haws, Manufacturer Part Number : 6810Model 6810 In-wall floor mounted fixture carrier: Two 2½” x 1½” x 1/8” thick structural steel uprights having 6” x 3" x 3/8” thick welded steel 4-bolt floor flanges, supplied with ‘U’ bolts and hardware. For use in conjunction with Haws in-wall mounting plates 6700, 6700.4, 6710, 6715, 6717, or 6776, for extra heavy duty fixture support. Fits inside standard 2” x 4” wall construction. Suitable for use with either 3/8" or 1/2" concrete anchors (by others). Includes mounting holes for plumbing stub out bracket and electrical boxes, and a on-site custom-fit side drain port. This port can be placed at any height. Exceeds requirements when tested in accordance to ASME Standard A112.6.1M. Design was independently verified as suitable to meet HCAI and CBC anchor spacing requirements.

Manufacturer: Haws, Manufacturer Part Number : MTGFR.17Model MTGFR.17 in-wall mounting frame is made of 16 gauge galvanized steel with welded-in heavy-duty 10 gauge mounting plate with pre-punched mounting holes, and is used with Haws H1117.8 series fountains.

Manufacturer: Haws, Manufacturer Part Number : MTGFR.7Model MTGFR.7 in-wall mounting frame is made of 16 gauge galvanized steel with welded-in heavy-duty 10 gauge mounting plate with pre-punched mounting holes, and is used with Haws H1107.8 series fountains.

Manufacturer: Haws, Manufacturer Part Number : MTGFR.DF1Model MTGFR.DF1 in-wall mounting frame is made of 16 gauge galvanized steel with welded-in heavy-duty 10 gauge mounting plate with pre-punched mounting holes. For use with Haws single 'swirl bowl' series fountains, and provides access to an in-wall trap.

Manufacturer: Haws, Manufacturer Part Number : MTGFR.DF2Model MTGFR.DF2 "Hi-Lo" in-wall mounting frame is made of 16 gauge galvanized steel with welded-in heavy-duty 10 gauge mounting plate with pre-punched mounting holes. For use with Haws 1011 series fountains, and provides access to the in-wall traps.

Manufacturer: Haws, Manufacturer Part Number : MTGFR.LGModel MTGFR.LG "Hi-Lo" in-wall mounting frame is made of 16 gauge galvanized steel with welded-in heavy-duty 10 gauge mounting plate with pre-punched mounting holes, and is used with Haws dual bubbler electric fountains.

Manufacturer: Haws, Manufacturer Part Number : MTGFR.SMModel MTGFR.SM in-wall mounting frame is made of 16 gauge galvanized steel with welded-in heavy-duty 10 gauge mounting plate with pre-punched mounting holes, and is used with Haws single bubbler electric fountains.

Manufacturer: Haws, Manufacturer Part Number : 6700Model 6700 in-wall 3/16" thick steel mounting plate is larger, thicker and stronger than any other plate in the industry, and shall include the all-thread studs, nuts, and washers. For use with many Haws single bubbler fountains.

Manufacturer: Haws, Manufacturer Part Number : 6700.4Model 6700.4 'Hi-Lo' in-wall 3/16" thick steel pre-drilled mounting plate is larger, thicker and stronger than any other plate in the industry, and shall include the all-thread studs, nuts, and washers. For use with many Haws dual bubbler fountains.

Manufacturer: Haws, Manufacturer Part Number : 6700RModel 6700R on-wall 3/16" thick steel mounting plate is stronger and thicker than any other plate in the industry. It is designed for retrofit installations and provides additional support for the installation of the 1920 series bottle filler to a wall. Plate is to be mounted on the surface of a finished wall and is concealed behind optional back panel. Steel construction provides a solid support system for Haws 1920, 1920HPS or 1920FR bottle fillers. Measurements are 14" W x 7" H x 3/16" (35.6 x 17.8 x .47 cm).
