Manufacturer: Haws, Manufacturer Part Number : 6635Model 6635 sand trap shall include a see through acrylic canister with lifting handle for 3500, 3511 and 3600 series fountains. (This option cannot be used in conjunction with the 6250LF bib faucet on 3511).

Manufacturer: Haws, Manufacturer Part Number : VRKHO2Model VRKHO2 is a cable repair kit for HO "Hands-Off" electric water coolers.

Manufacturer: Haws, Manufacturer Part Number : VRKHO3Model VRKHO3 is a solenoid valve for HO "Hands-Off" sensor operated electric water coolers manufactured before October 1st, 2021.

Manufacturer: Haws, Manufacturer Part Number : H7149MSModel H7149MS wall mounting shelf is designed to support most remote chillers in order for chiller to be off the floor and tucked out of the way. Made of heavy gauge galvanized steel. Shelf size is 25 - 1/8" x 13" (63.8 x 33 cm). Note: When installing chiller on shelf in a remote location, adequate air circulation and access must be provided for chiller.

Manufacturer: Haws, Manufacturer Part Number : 6810WModel 6810W is an option for the 68oo in-wall support carrier produced after August of 2023. This custom-fit side drain port can be installed in the field to allow a waste drain to be installed outside of the carrier.

Manufacturer: Haws, Manufacturer Part Number : 5452LFModel 5452LF is a polished chrome-plated brass lever handle, self-closing gooseneck faucet with a vandal-resistant .5 gpm (1.9 L) aerator, vandal-resistant lock pin, and 1/2" O.D. (1.3 cm) slip-joint inlet.

Manufacturer: Haws, Manufacturer Part Number : 5510LFModel 5510LF is a polished chrome-plated brass stay-open lever handle, compression gooseneck faucet with a vandal-resistant .5 gpm (1.9 L) aerator, vandal-resistant lock pin, and 1/2" O.D. (1.3 cm) slip-joint inlet.

Manufacturer: Haws, Manufacturer Part Number : 5551Model 5551 is a self-closing, cold-water gooseneck glassfiller faucet with push-lever operation and polished chrome-plated brass finish, and 3/8" NPT inlet. Mounting hardware not included.

Manufacturer: Haws, Manufacturer Part Number : SK11Model SK11 stainless steel skirt is the outer apron for the 1201 series Haws water coolers (not for "Hi-Lo" units).

Manufacturer: Haws, Manufacturer Part Number : SK13Model SK13 stainless steel skirt is the outer apron for the lower or "Lo" portion of the 1202 and 1212 series Haws "Hi-Lo" water coolers. (For the upper skirt, see model SK12)

Manufacturer: Haws, Manufacturer Part Number : SK12Model SK12 stainless steel skirt is the outer apron for the upper or "Hi" portion of the 1202 and 1212 series Haws "Hi-Lo" water coolers. (For the lower skirt, see model SK13)

Manufacturer: Haws, Manufacturer Part Number : 6433Model 6433 is a lead-free, celcon Y pattern water strainer with removable 100 mesh screen for easy cleaning. 1/4" NPT(F) inlet and outlet. 1-7/8" (4.8 cm) long with strainer arm extending to 2-15/16" (5.6 cm) overall width.

Manufacturer: Haws, Manufacturer Part Number : 6437The Haws 6437 in-line Y-strainer is used for the Haws 1200 series water coolers. The Noryl plastic strainer uses a 100 mesh screen and is attached at the cold water inlet.

Manufacturer: Haws, Manufacturer Part Number : 6438Model 6438 is a three-hole stainless steel strainer nipple used to connect the bubbler head to the valve.

Manufacturer: Haws, Manufacturer Part Number : 6469The Haws 6469 drip tray is used as a retrofit accessory for the Haws 1920 bottle filler when mounting it over the Haws 1109 style of drinking fountains. Easy mounting instructions allow this tray to quickly convert the 1109 series to a bottle filling station. Made of 304 stainless steel, the upper portion can be easily removed, allowing the unit to be cleaned.

Manufacturer: Haws, Manufacturer Part Number : 6800Model 6800 universal support shall include dual steel tube supports with integral 3/16" (.47 cm) steel mounting feet along with u-bolts and hardware.

Manufacturer: Haws, Manufacturer Part Number : 6470This drain kit allows the 2000SMS to be plumbed to a waste outlet. Drain kit includes waste strainer and 1-1/4" (3.2 cm) OD tailpiece and all accompanying washers/nuts to attach strainer to tailpiece. A trap will not be included. Current design of the drain trays allows for pop-out of drain kit assembly.

Manufacturer: Haws, Manufacturer Part Number : 5810The Haws model 5810 cold water control regulates the cold water temperature for the 1200 series Haws water coolers.

Manufacturer: Haws, Manufacturer Part Number: 9201E Model 9201E emergency mixing valve (patent pending) thermostatically mixes hot and cold water to provide a safe fluid supply for emergency showers and eyewash equipment. Additionally, to ensure a fail-safe water supply for emergency shower and eyewash stations, a series of cold water by-pass valves open in the event of hot water pressure loss. (No gauges supplied - ASSE 1071 standard recommends gauges be placed 5 to 8 feet (1.52 to 2.44 m) downstream for the most accurate temperature measurement.) -Optional recessed or surface mounted valve box available -A flow rate of 1 to 31 gpm (3.8 to 117.3 L) for better temperature control across the operating range -AXION's superior design and technology provide a complete safety solution for increased victim comfort -Lowest internal pressure drop for this class of valve (advantage where supply pressure is low) -Wax based thermostat technology for fast response time with proven highly reliable temperature control -Highest Cold Water Bypass flow rate in the industry (65% of rated tepid flow rate) -Brass valve design with internal check stops -Over-sized valve seats resist failures caused by foreign matter -A new and efficient shuttle design eliminates valve sticking -A custom funnel design improves temperature control at low flow rates -Outlet temperature is factory set to 85° F (29° C) -Tempered water: High temperature limit is factory set to 90° F (32° C) -Cold water by-pass valves are closed during normal operation, regardless of flow rate -For important installation information, please read Scald Warning. -CSA Listings: CSA certified per ASSE 1071, ANSI Z358.1, and applicable sections of CSA B125.3.

Manufacturer: Haws, Manufacturer Part Number: 9201EFE Model 9201EFE Emergency Thermostatic Mixing Valve (patent pending) thermostatically mixes hot and cold water to provide a safe fluid supply for emergency eyewash equipment. Additionally, to ensure a fail-safe water supply for emergency eyewash stations, a series of cold water by-pass valves open in the event of hot water pressure loss. (No gauges supplied - ASSE 1071 standard recommends gauges be placed 5 to 8 feet (1.52 to 2.44 m) downstream for the most accurate temperature measurement.) -Optional recessed or surface mounted valve box available -A flow rate of 1 to 12 gpm (3.8 to 45.4 L) for better temperature control across the operating range -AXION's superior design and technology provide a complete safety solution for increased victim comfort -Lowest internal pressure drop for this class of valve (advantage where supply pressure is low) -Wax based thermostat technology for fast response time with proven highly reliable temperature control -Highest Cold Water Bypass flow rate in the industry (83% of rated tepid flow rate) -Brass valve design with internal check stops -Over-sized valve seats resist failures caused by foreign matter -A new and efficient shuttle design eliminates Thermostatic Mixing Valve sticking -A custom funnel design improves temperature control at low flow rates -Outlet temperature is factory set to 85° F (29° C) -Tempered water: High temperature limit is factory set to 90° F (32° C) -Cold water by-pass valves are closed during normal operation, regardless of flow rate -For important installation information, please read Scald Warning. -CSA Listings: CSA certified per ASSE 1071, ANSI/ISEA Z358.1 and applicable sections of CSA B125.3.

Manufacturer: Haws, Manufacturer Part Number: 9201EW Model 9201EW Emergency Valve thermostatically mixes hot and cold water to provide a safe fluid supply for a single emergency eye/face wash. Additionally, to ensure a fail-safe water supply for emergency eyewash stations, a cold water by-pass valves open in the event of hot water pressure loss. (No gauges supplied - ASSE 1071 standard recommends gauges be placed 5 to 8 feet (1.52 to 2.44 m) downstream for the most accurate temperature measurement.) -A flow rate of 1 to 10 gpm (3.8 to 37.8 L) for better temperature control across the operating range -AXION's superior design and technology provide a complete safety solution for increased victim comfort. -Wax based thermostat technology for fast response time with proven highly reliable temperature control -Cold Water Bypass flow rate of 3.8 gpm (14.4 L) (When tested under conditions specified in ASSE 1071) -Brass valve design with supplied check valves -Over-sized valve seats resist failures caused by foreign matter -Efficient funnel design improves temperature control at low flow rates -Outlet temperature is factory set to 85° F (29° C). -Tempered water: High temperature limit is factory set to 90° F (32° C). -For important installation information, please read Scald Warning. -CSA Listings: CSA certified per ASSE 1071, ANSI/ISEA Z358.1, NSF/ANSI/CAN 372, and applicable sections of CSA B125.3.

Manufacturer: Haws, Manufacturer Part Number: 9201HModel 9201H, low-lead Emergency Valve (patent pending), thermostatically mixes hot and cold water to provide a safe fluid supply for emergency showers and eyewash equipment. The valve contains a secondary high temperature limit valve to provide additional protection to the user in the event of main tempering valve malfunction. Additionally, to ensure a fail-safe water supply for emergency shower and eyewash stations, a series of cold water by-pass valves open in the event of hot water pressure loss. (No gauges supplied - ASSE 1071 standard recommends gauges be placed 5 to 8 feet downstream for the most accurate measurement.) -Optional recessed or surface mounted valve box available -A flow rate of 1 to 31 gpm (3.8 to 117.3 L) for better temperature control across the operating range -AXION's superior design and technology provide a complete safety solution for increased victim comfort -Lowest internal pressure drop for this class of valve (advantage where supply pressure is low) -Wax based thermostat technology for fast response time with proven highly reliable temperature control Highest Cold Water Bypass flow rate in the industry (65% of rated tepid flow rate) -Low-lead brass valve design with internal check stops -Oversized valve seats resist failures caused by foreign matter -A new and efficient shuttle design eliminates valve sticking -A custom funnel design improves temperature control at low flow rates -Outlet temperature is factory set to 85° F (29° C) -Tempered water: High temperature limit is factory set to 87° F (30° C) -Cold water by-pass valves are closed during normal operation, regardless of flow rate -Listings: CSA certified per ASSE 1071, ANSI Z358.1, applicable sections of CSA B125.3, NSF/ANSI 372, NSF/ANSI 61-section 8, California Health and Safety Code 116875 (AB 1953).

Manufacturer: Haws, Manufacturer Part Number: 9202E Model 9202E Emergency Valve (patent pending) thermostatically mixes hot and cold water to provide a safe fluid supply for emergency showers and eyewash equipment. Additionally, to ensure a fail-safe water supply for emergency shower and eyewash stations, a series of cold water by-pass valves open in the event of hot water pressure loss. (No gauges supplied - ASSE 1071 standard recommends gauges be placed 5 to 8 feet (1.52 to 2.44 m) downstream for the most accurate measurement.) -Optional recessed or surface mounted valve box available -A flow rate of 1 to 78 gpm (295 L) for better temperature control across the operating range -Lowest internal pressure drop for this class of valve (advantage where supply pressure is low) -Wax based thermostat technology for fast response time with proven highly reliable temperature control -Highest Cold Water Bypass flow rate in the industry (64% of rated tepid flow rate) -Brass valve design with internal check stops -Over-sized valve seats resist failures caused by foreign matter -A new and efficient shuttle design eliminates valve sticking -A custom funnel design improves temperature control at low flow rates -Outlet temperature is factory set to 85° F (29° C) -Tempered water: High temperature limit is factory set to 90° F (32° C) -Cold water by-pass valves are closed during normal operation, regardless of flow rate -For important installation information, please read Scald Warning. -CSA Listings: CSA certified per ASSE 1071, ANSI Z358.1 and applicable sections of CSA B125.3.

Manufacturer: Haws, Manufacturer Part Number : PBA6Model PBA6 flanged push button assembly is used with push button valve 5874, is made of polished chrome-plated brass, and includes the push button, operator, round locknut, snap ring, and wave washer. This model is used on flush mounted (not recessed) front stainless steel drinking fountain models.
